NEXDUSTRY ND-AFBC-1000 Flat Belt Conveyor Specification
| Item | Specification |
|---|---|
| Product Name | Flat Belt Conveyor |
| Support Material | Aluminum Extruded Profile |
| Belt Material | PVC 2.0mm |
| Motor Power | 90W |
| Load Capacity | <30kg |
| Conveyor Size (L × W × H) | 1000 × 200 × 750 mm (39″ × 8″ × 30″) |
| Height Adjustment Range | 0.39″ |
| Running Speed Options | 49–66 ft/min (15–20 m/min) |
| Product Weight | 80 kg (176.37 lbs) |
| Control System | Electronic Speed Controller |
| Mobility | 4 lockable caster wheels |
| Packaging | Wooden Case |
| Packing Weight | 10 kg |
| Packing Dimensions (L × W × H) | 1060 × 630 × 1200 mm |
| Power Cord Length | 5 m (16.4 ft) |
Flat Belt Conveyor Design
Why NEXDUSTRY’s Flat Conveyor?
This mobile belt conveyor (39″ × 8″ W) features lockable swivel casters for easy movement and secure positioning. Built with a durable frame and stable belt tracking, it ensures smooth, reliable conveying for packaging, assembly, and light-to-medium industrial applications
